RFT
Product description
The RFT multi-leaf sliding folding door is the ideal solution for large and flexible openings with widths from 2.500 mm to 12.000 mm. With robust frame profiles from 80 mm and glass thicknesses up to 46 mm, it offers excellent thermal insulation (U-value ≥ 2,2 W/m²K) and sound insulation up to 25 dB.
Available in semi-automatic or power-operated versions, it offers high security and energy efficiency. The gate is suitable for both commercial and private applications and can be installed without a threshold, which further increases comfort and functionality.
| Range of Measurements (RBM): Width: Height: |
2.500-12.000 2.500-6.000 |
| Wing width: | 800-1.500 |
| Possible division: | 1:2/2:1/1:3/3:1/2:2/2:3/3:2/3:3/3:4/4:3/4:4 |
| Other variants: | multi-leaf sliding folding door |
| Installation depth: | 80/80/3 with rolled glazing bar |
| Material | Sheet thickness | Surface: | 80 |
| Opening angle (manually operated): | to 180 ° |
| Opening angle (power operated): | Inline |
| Glazing: | Rectangular glazing insulating glass as safety glass, glass thickness 24 – 46 mm |
| Drive types: | Semi-automatic, fire department opening, power-operated central drive, 1 lifting spindle drive per sash package |
| wicket door: | possible, with/without threshold |
| divided walking wing: | / |
| Fitting: | Deadbolt concealed |
| Burglar resistance: | WK 3 |
| Sound insulation: | 25 dB |
| Thermal transmittance coefficient: | Uₓ ≥ 2,2 W/(m²K) |
| Resistance to wind load: | / |
| Air permeability: | / |
| Driving rain tightness: | / |
| ventilation grille: | / |
| Steering: | HPS-Motion II | SPS-Control |
